Radiator with Fan for Honda Civic 1992-2000, Acura Integra 1994-2001, Civic del Sol 1993-1997, 2-Row 30mm Core Replace HO3010123 BDFHYK

Restore and upgrade cooling performance with this direct-fit replacement radiator kit for select Honda Civic, Honda Civic del Sol, Acura Integra, and Acura EL applications. Built with a 2-row, 30 mm aluminum core and supplied with an electric cooling fan, it is designed to replace an aged, leaking, clogged, corroded, or damaged factory radiator while supporting airflow during idling, stop-and-go traffic, and low-speed driving.

Vehicle Fitment & OE Reference Numbers

OE / Interchange Reference Numbers: HO3010123, HO3010125, 19010-P07-014, 19010-P07-024, SRW129.

Before ordering: Compare the OE number, overall dimensions, inlet and outlet positions, mounting points, drain location, fan mounting area, and engine-bay clearance with the original setup.

Product Specifications & Package Includes

Package Includes: 1 × 2-row 30 mm radiator, 1 × electric cooling fan, and 1 × instruction manual.

Signs Your Radiator Needs Replacement

• The engine temperature runs higher than normal or the vehicle overheats.
• Coolant leaks appear around the radiator, seams, hose connections, drain area, or lower corners.
• The coolant level drops repeatedly without an obvious hose leak.
• Cooling fins are bent, clogged, corroded, or damaged.
• Airflow is insufficient during idling or stop-and-go traffic.
• The temperature gauge fluctuates during low-speed or warm-weather driving.

Replacing an aged radiator and improving low-speed airflow can help restore coolant circulation and reduce the risk of repeated overheating.

Key Features & Benefits

2-Row 30 mm Aluminum Core: Provides increased cooling surface area and supports efficient heat transfer.

Electric Cooling Fan Included: Supports airflow during idling and low-speed driving where natural airflow is limited.

Vehicle-Specific Fitment: Designed around compatible Honda and Acura mounting and hose locations.

Stable Daily Cooling: Helps maintain engine temperature during commuting, city traffic, highway use, and warm-weather operation.

Complete Cooling Package: Combines the radiator, electric fan, and instruction manual in one kit.

Installation Notes & 4-Step Guide

Important: Confirm fan clearance, mounting orientation, wiring requirements, and airflow direction before installation. Professional installation is recommended if you are not experienced with cooling-system or electrical work.

1. Drain: Allow the engine to cool completely, remove the radiator cap carefully, and drain the old coolant.
2. Remove: Disconnect the radiator hoses, overflow hose, fan or shroud components, and mounting hardware.
3. Install: Compare both radiators, install the new unit, and mount the electric fan with proper clearance and airflow direction.
4. Refill & Test: Reconnect all hoses, refill with the recommended coolant mixture, bleed trapped air, verify fan operation, and inspect for leaks.

After installation: Inspect hoses, clamps, radiator cap, thermostat, water pump, wiring, fan direction, and fan clearance. Recheck coolant level and mounting points after the first drive.
