Rear drive shaft assembly for 2007-2014 Ford Edge and Lincoln MKX 3.5L V6 AWD

Rear Driveshaft Assembly for 2007-2014 Ford Edge Lincoln MKX 3.5L V6 AWD Automatic Replace 936-846 | BDFHYK

$339.99

Product Detail

Type Drive Shaft Assembly
SKU BDDLZ-BD-05-03-00006BK-000-W
OE Number DT4Z-4R602-A, DT4Z4R602A, 7T4Z4R602A, SK936846, 936-846, 65-2027

⛟ Estimated Delivery: Calculating... · Ships by Calculating... · Free Shipping

Trust & Assurance

Free Shipping · 2–7 Business Days

12-Month Warranty

30-Day Return

Secured Payment

This BDFHYK rear drive shaft is listed for 2007-2014 Ford Edge and Lincoln MKX models with the 3.5L V6, AWD and an automatic transmission. Driveshaft fitment depends on drivetrain, position and original shaft configuration, so confirm the rear position, AWD system and 936-846 / listed OE references before ordering.

Ford Edge and Lincoln MKX Rear Driveshaft Fitment

2007-2014 Ford Edge: 3.5L V6, AWD, automatic transmission, rear position.
2007-2014 Lincoln MKX: 3.5L V6, AWD, automatic transmission, rear position.

Product Specifications

Product Type	Complete Driveshaft Assembly
Position	Rear
Drive Type	AWD
Engine	3.5L V6
Transmission	Automatic
Material	Steel
Wall Thickness	0.083 in
Balance	High-Speed Dynamic Balanced
OE / Interchange References	936-846, 7T4Z4R602A, 9T4Z4R602A, BT4Z4R602A, DT4Z4R602A

What to Check Before Ordering

Confirm the exact model year, 3.5L V6, AWD drivetrain and rear position.
Compare 936-846 and the listed OE/interchange references with the original part or a reliable parts catalog.
Compare the removed shaft's length, end connections and overall layout before installation.
Do not select this part only by the Edge or MKX model name because drivetrain configuration matters.

Driveline Symptoms and Diagnosis

Vibration, clunking, squeaking or shudder can be associated with a driveshaft or joint problem, but these symptoms do not confirm that the shaft itself has failed. Inspect joints, mounts, wheel and tire assemblies, transmission or transfer components, differential components and other driveline parts before replacement.

Installation Notes

Compare the replacement assembly with the removed shaft before installation and preserve any required orientation or phasing information. Follow the vehicle manufacturer's service procedure and tightening specifications. This is a BDFHYK aftermarket replacement part; OE/interchange numbers are provided for identification and fitment comparison.

Technical Specifications

Brand	BDFHYK
Product Type	Complete Driveshaft Assembly
Position	Rear
Drive Type	AWD
Listed Vehicle Fitment	2007-2014 Ford Edge; 2007-2014 Lincoln MKX
Engine	3.5L V6
Transmission	Automatic
Weld-to-Weld Length	OE Matched
Compressed Length	OE Matched
Extended Length	OE Matched
Spline Count	OE Matched
Shaft Material	Steel
Wall Thickness	0.083 in
Balance Method	High-Speed Dynamic Balanced
OE / Interchange References	936-846, 7T4Z4R602A, 9T4Z4R602A, BT4Z4R602A, DT4Z4R602A
Includes	1 Driveshaft Assembly
Important Note	Confirm model year, 3.5L V6, AWD drivetrain, rear position, OE/interchange references and original shaft configuration before ordering.

Ford Edge & Lincoln MKX Rear Drive Shaft FAQs

Q: Will this rear drive shaft fit my Ford Edge?

A: The listed fitment is 2007-2014 Ford Edge with the 3.5L V6, AWD, automatic transmission and rear position.

Q: Will this driveshaft fit a Lincoln MKX?

A: The listed fitment is 2007-2014 Lincoln MKX with the 3.5L V6, AWD, automatic transmission and rear position.

Q: Is this driveshaft for AWD applications?

A: Yes. The listed Edge and MKX applications are AWD. Do not extend the fitment to a different drivetrain unless separately verified.

Q: Is this a front or rear driveshaft?

A: This product is listed for the rear position.

Q: Which engine and transmission are listed?

A: The current product data lists the 3.5L V6 with an automatic transmission.

Q: Which OE or interchange numbers should I compare?

A: Compare 936-846, 7T4Z4R602A, 9T4Z4R602A, BT4Z4R602A and DT4Z4R602A with the original part or a reliable catalog.

Q: What material is the driveshaft made from?

A: The current product specifications list steel shaft construction with a 0.083-inch wall thickness.

Q: Are numeric length and spline values available?

A: The current listing states that key length and spline specifications are OE matched, but it does not publish numeric values. Compare the removed shaft before installation.

Q: Is the driveshaft dynamically balanced?

A: Yes. The current product data states that the assembly is high-speed dynamically balanced. No specific balance RPM should be assumed.

Q: Can vibration or clunking prove that the driveshaft is bad?

A: No. Similar symptoms can come from joints, mounts, wheels and tires, transmission or transfer components, differential components and other driveline parts.

Q: What should I check before installation?

A: Compare the replacement assembly with the removed shaft, including position, overall layout and connection points, then follow the vehicle manufacturer's service procedure.

Q: Is this a genuine Ford or Lincoln OEM driveshaft?

A: No. This is a BDFHYK aftermarket replacement driveshaft. OE/interchange references are provided for identification and fitment comparison.
